DERCHI AS2047 Aluminium Double Glass Bi-Fold Patio Doors

The DERCHI 80 Series Aluminium Bi Fold Patio Door is a precision-engineered, thermally insulated aluminum folding door solution purpose-built for modern outdoor living — serving residential balconies, private garden access points, luxury villa exteriors, and commercial patio enclosures across the Australian, American, and European markets. Constructed from robust 6063-T5 thermal break aluminum (2.0 mm wall thickness) and finished in a clean modern design, this bi-fold door delivers dependable soundproof performance, proven waterproof integrity, and lasting structural durability across all climate environments.
Equipped as standard with American brand CMECH hardware and 5 mm + 20A + 5 mm double-tempered insulated glass with argon gas filling, this door offers a versatile performance profile suited to a wide range of residential, garden, and commercial settings. Screen netting options — Nylon and Fiberglass — support free-flowing ventilation while blocking insects, making the door a preferred choice for open-air garden living and alfresco dining environments. Glass upgrades to Low-E, laminated, reflective, and tinted configurations are available to satisfy specific energy efficiency and acoustic project demands. Triple tempered glass with argon gas is also available for enhanced thermal and acoustic insulation.

KEY ADVANTAGES

01

Engineered for Modern Outdoor Living & AS2047 Certified Performance

Crafted specifically for the modern outdoor living lifestyle, this bi-fold patio door bridges interior comfort with exterior openness through its wide-span folding panels. The thermal break 6063-T5 aluminum frame (2.0 mm wall thickness) is engineered for superior structural integrity — protecting residences, garden-access spaces, and commercial outdoor areas from wind pressure and weather exposure. Certified to AS2047 Australian standards, NFRC, and CE, this door meets the most stringent international building codes. Whether installed on an Australian coastal home, a European villa garden entrance, or an American backyard patio, this door’s robust construction safeguards occupants while delivering the panoramic open-air experience essential to modern outdoor living culture.
02

CMECH Hardware: American Quality, Smooth Folding Operation

CMECH American brand hardware is the standard fitting for this bi-fold door — a trusted hardware brand recognized for consistent operating performance and long-term reliability in folding door applications. All CMECH hardware components feature corrosion-resistant construction rated for hundreds of thousands of folding cycles, making them especially suited to outdoor environments exposed to humidity, salt air, and temperature fluctuations. The precision-engineered folding mechanism ensures effortless panel-by-panel operation, allowing homeowners to fully open their living space to the outdoors in seconds.
03

Thermal Insulation & Soundproof Performance

The thermal break aluminum profile design creates an effective barrier against heat transfer, significantly reducing energy consumption for heating and cooling. Combined with double-tempered insulated glass filled with argon gas (5mm+20A+5mm), this bi-fold door delivers exceptional thermal insulation performance — keeping interiors cool in summer and warm in winter. The multi-chamber profile structure and sealed glass unit also provide outstanding soundproof capabilities, reducing external noise penetration by up to 35 dB, creating a peaceful indoor environment even in busy urban or roadside locations.
04

Screen Netting & Versatile Ventilation

Available in both Nylon and Fiberglass screen netting configurations, this bi-fold door accommodates the full spectrum of outdoor living needs. The fiberglass screen provides superior durability and resistance to UV degradation and deformation — ideal for long-term outdoor installations. Nylon screens offer a flexible, cost-effective ventilation solution for residential balconies and patio enclosures. When the bi-fold panels are fully opened, the screen netting maintains insect protection while allowing maximum airflow — perfect for tropical and subtropical climates where natural ventilation is essential to comfortable outdoor living.
05

Powder Coated & PVDF Surface with Modern Aesthetic

The standard powder coating or PVDF surface treatment provides exceptional long-term UV resistance, anti-corrosion protection, and color consistency — delivering lasting beauty that holds up through intense UV exposure, coastal salt air, and high-humidity outdoor conditions. The modern design aesthetic of the 80 Series profile, with its clean sightlines and slim frame geometry, complements contemporary residential architecture, open-plan garden living extensions, and minimalist facade systems. Available colors include White, Black, Grey, Bronze, Champagne, Dark Brown, and fully customizable RAL or Pantone specifications.
06

Global Export Track Record & Comprehensive After-Sale Service

DERCHI actively exports to 50+ countries with established B2B supply chains serving Australia, the US, Canada, Europe, Southeast Asia, the Middle East, and Latin America. The after-sale program extends well beyond standard support: DERCHI offers online technical assistance, onsite installation guidance, onsite training, onsite inspection, and return and replacement services. The in-house graphic design team produces professional project visualizations, facade renders, and product proposal assets that empower buyers to win commercial contracts and close sales with their end clients. Full CAD shop drawings, section profiles, and technical calculations are provided at no extra charge, supporting the complete project cycle from initial design concept through delivery and installation.

PRODUCT PARAMETERS

Specification	Details
Series	80 Series Aluminum Glass Folding Door
Brand	DERCHI
Model Number	80 Series Bi-Fold Doors
Product Name	Thermal Break Aluminum Folding Door
Profile	6063-T5 Thermal Break Aluminum Profile
Aluminum Thickness	2.0 mm
Available Size	Opening Panel: Width 500–850 mm / Height 1900–3000 mm (Custom sizes available)
Door Material	Aluminum Alloy (6063-T5) + Glass
Glass Type	Double Tempered Glass with Argon Gas; Triple Tempered Glass with Argon Gas; Laminated / Low-E / Reflective / Tinted Glass
Glass Thickness (IGU)	5 mm + 20A + 5 mm / 6 mm + 18A + 6 mm / 8 mm + 14A + 8 mm
Hardware	CMECH (American Brand, standard)
Surface Finishing	Powder Coated (standard); PVDF Coating
Design Style	Modern
Screen Netting Material	Nylon; Fiberglass
Position / Application	Outdoor, Indoor; Exterior, Balcony, Patio, Villa, Residential House
Opening Method	Foldable (Bi-Fold)
Feature / Advantage	Waterproof, Heat Insulation, Thermal Insulation, Soundproof
Warranty	More Than 5 Years
After-Sale Service	Online Technical Support; Return and Replacement; Onsite Inspection; Onsite Training; Onsite Installation
Certificate	NFRC / AS2047 / CE / ISO 9001

APPLICATIONS

01

Residential Spaces
02

Commercial Environment
03

Public & Institutional
04

Leisure Infrastructure

CUSTOM DOORS

Details

product color

Customizable Styles

CERTIFICATES OBTAINED

PACKING

FREQUENTLY ASKED QUESTIONS

Q1: Does this bi-fold patio door meet international building standards? What certifications does DERCHI hold?

A: Yes. This 80 Series Bi-Fold Patio Door is certified to AS2047 (Australian Window Standard), NFRC (National Fenestration Rating Council), CE (European Conformity), and ISO 9001 quality management standards. The thermal break aluminum frame (6063-T5, 2.0 mm wall) and sealed double-tempered glass unit deliver proven structural and thermal performance. DERCHI’s manufacturing facility holds ISO 9001, ISO 14001, and ISO 45001 certifications, and the company holds 100+ product certificates and patents. Comprehensive certification documentation is available on request for project submissions, building permit applications, and import compliance review.
Q2: What glass configurations are available for this bi-fold door?

Our standard build uses 5 mm + 20A + 5 mm double-tempered insulated glass with argon gas. The following options are also available:
•6 mm + 18A + 6 mm double-tempered glass with argon gas — for enhanced impact resistance
•8 mm + 14A + 8 mm double-tempered glass with argon gas — for maximum strength applications
•Triple tempered glass with argon gas — for superior thermal and acoustic insulation
•Low-E coated glass — for improved solar heat rejection and energy efficiency
•Acoustic laminated glass — for sound attenuation in urban and high-traffic environments
•Reflective and tinted glass — for solar heat gain control in hot climate regions
Q3: What hardware is fitted as standard, and can I specify alternatives?

A: CMECH (American Brand) is the standard hardware specification for this 80 Series Bi-Fold Door. CMECH is recognized for its precision folding mechanism, corrosion resistance, and long-cycle durability — making it an ideal choice for outdoor bi-fold applications. For buyers with specific project requirements or regional preferences, alternative hardware brands can be discussed and sourced upon request.
Q4: What surface treatment options are available?

A:Two primary surface treatment options are available:
•Powder Coated (standard) — durable, cost-effective, available in a wide range of colors
•PVDF Coating — premium option with superior UV resistance and color retention for 15+ years
Both treatments provide excellent anti-corrosion protection suitable for coastal and high-humidity environments. Available colors include White, Black, Grey, Bronze, Champagne, Dark Brown, and fully customizable RAL or Pantone specifications.Our standard build uses 5 mm + 20A + 5 mm double-tempered insulated glass with argon gas. The following options are also available:
•6 mm + 18A + 6 mm double-tempered glass with argon gas — for enhanced impact resistance
•8 mm + 14A + 8 mm double-tempered glass with argon gas — for maximum strength applications
•Triple tempered glass with argon gas — for superior thermal and acoustic insulation
•Low-E coated glass — for improved solar heat rejection and energy efficiency
•Acoustic laminated glass — for sound attenuation in urban and high-traffic environments
•Reflective and tinted glass — for solar heat gain control in hot climate regions
Q5: What are the available sizes for this bi-fold door?

The standard available size for each opening panel is Width 500–850 mm and Height 1900–3000 mm. Multiple panels can be combined to create wide-span openings — common configurations include 2-panel, 3-panel, 4-panel, 5-panel, and 6-panel arrangements. Custom sizes beyond the standard range can be engineered upon request to suit specific architectural requirements.
Q6: What after-sale services does DERCHI provide?
DERCHI offers a comprehensive after-sale service package including:
- Online Technical Support — remote troubleshooting and installation guidance
- Onsite Installation — professional installation team available for project sites
- Onsite Training — hands-on training for local installation crews
- Onsite Inspection — quality verification at project completion
- Return and Replacement — hassle-free warranty claims processing
- Graphic Design Project Solutions — professional renders, visualizations, and proposal materials
- CAD Shop Drawings — detailed engineering drawings provided free of charge
Q7: How are products packaged and shipped internationally?
Our export packaging is engineered to guarantee damage-free arrival at any global port:
- Full-surface protective film applied to all aluminum profiles before packaging
- High-density foam corner protectors cushion all frame edges against transit impact
- ISPM-15 certified fumigation-free wooden or steel pallets meet international customs requirements
- Air-bag container securing system prevents load shifting during ocean transit
- Each shipment includes packing list, commercial invoice, and Certificate of Origin
We support FOB, CIF, CFR, and EXW trade terms with extensive experience in ocean freight to ports worldwide.
